Swiss Screw Machining
SWISS SCREW MACHINING SERVICES
With over 35 years’ expertise in Swiss screw machining, Ed’s Precision Manufacturing, LLC of Houston, TX, knows all the ins, outs, ups, and downs of boring, drilling, knurling, milling, polishing, reaming, slotting, and CNC turning. We’re also excellent with threading, having extensive familiarity with external thread cutting, internal thread cutting, premium threads, and tapping.
You name the metal or material, we’ll have it back to you in almost no time (indeed, we pride ourselves here on specializing in rush-jobs). Alloy steels, brass, bronze alloys, monel, inconel, super alloys, titanium, and stainless steel have all met their match at the hands of our Swiss screw machining. The same can be said for, nylon, delrin, peak plastic, and PVC. We’ll fashion any material into parts with diameters, lengths, and features of respectively from 1/16th to 1.5 inches in diameter, 1/16th x 18 inches in length, and tightness tolerances of ± .0002 in.
We’re happy to handle Just-in-time (J.I.T) deliveries and blanket orders. And we’ve got the necessary equipment as well as the skills, featuring 10-axis capability and a Swiss machine bar-feeder equipped for lights-out manufacturing. For more information about Ed’s Precision Manufacturing LLC, please consult the chart below, call us today at 713.956.1112, or email us at sales@edsprecision.com.
SWISS SCREW MACHINING CAPABILITIES
| Processes (General Capabilities) | Boring Drilling Hexing Knurling Milling | Polishing Reaming Slotting Turning |
| Processes (Threading) | External Thread Cutting Internal Thread Cutting | Premium Threads Tapping |
| Tolerances | ± .0002 in | |
| Part Diameter | Min 1/16" | Max 1 ½" |
| Part Length | Min 1/16" | Max 1 ½" |
| Part Feature | Min 1/16" | Max 18" |
| Materials (Metals) | Alloy Steels Aluminum Brass Bronze Alloys Carbon Steel Cobalt Copper Duplex Low Carbon Steel Inconel Molybdenum | Monel Nickel Stainless Steel
Titanium Tool Steel |
| Materials (Plastic Polymers) | Nylon Delrin | Peak Plastic PVC (Polyvinyl Chloride) |
| Equipment Capabilities | CNC Controlled Bar Feeder Equipped | 6-Axis |
| Production Volume | Min 25 Pieces Prototype Low Volume High Volume | Max 100,000 Plus Pieces |
| Lead Times Available | 4 Weeks or Less Standard Turn Around 24 Hour Emergency Service | Just In Time (J.I.T.) Deliveries |
| Secondary/ Value Added Services Offered | Anodizing Coating Cost Engineering Heat Treatment Inspection Metal Sourcing Magnetic Particle (Mag Particle) NACE | Painting Part Number Engraving Sterilization Testing Tensile & Yield Welding Over-Lay Welding Ultra Sound (UT) |
| Industry Focus | Aerospace Agricultural Auto/Truck/Transportation Chemical Dental Electronic Energy Food Machine Tool | Marine Medical Military Nuclear Oil Field OEM Parts OEM Products Solar Wind Power |
| We Serve a Large Range of Industries: Please Inquire | ||
| Intended Application | Bonnets Connectors Fasteners Fittings OEM Fasteners Pipe Plugs Set Screws | Shafts Socket Heads Special Fasteners Specialty Fasteners Stems Valves |
| We Produce a Large Range of Components: Please Inquire for your Needs | ||
| Industry Standards | ANSI American National Standards Institute ASME American Society of Mechanical Engineers ASTM American Society for Testing and Materials DOT Department of Transportation FDA Food And Drug Administration | Mil-Spec Military Specifications NACE North American Association of Corrosion Engineers NRC Nuclear Regulatory Commission PED Standards Pressure Equipment Directive SAE Society of Automotive Engineers |
| Efficiency | Lights Out Manufacturing | |
| File Formats | AutoCAD (DWG) BMP Bit Mapped Graphics DXF Drawing Interchange Format, or Drawing Exchange Format GIF Graphics Interchange Format IGES Initial Graphics Exchange Specification, ANSI file format. JPG or JEPG Joint Photographic Experts Group | MasterCam 3D Model NACE North American Association of Corrosion Engineers Portable Document Format STEP Standard for the Exchange of Product Model Data TIFF Tagged Image File Format |
